VSI Vertical Shaft Impact Sandmaking

VSI Crusher provides efficient sand making and shaping using advanced German technology.

Capacity: 60-520 t/h Feeder Opening Size: ≤50 mm Power: 380 v:50 Hz

Get Quotes Whatsapp Engineer

Material

Suitable for crushing and shaping various hard materials, including river pebbles, granite, basalt, limestone, and artificial sand (for construction, highway, and railway applications).

Application

Widely used in construction aggregates, highway/railway engineering, water conservancy projects, and artificial sand production—ideal for high-quality sand making and material shaping.

Product Features

Superior Particle Shape: Optimized rotor design for cubical, well-graded products

Hydraulic Pressure Adjustment: Easy maintenance and quick gap setting

Automated Lubrication System: Ensures stable operation and reduces downtime

High Efficiency & Low Energy Consumption: Advanced crushing technology for maximum throughput

Robust Wear-Resistant Parts: Extended service life with world-class materials

Stable Performance: Suitable for continuous heavy-duty operation

Specification

Model		VSI-7611	VSI-8518	VSI-9526	VSI-1140
Capacity	Cascade and Center Feeding	120-180	200-260	300-380	450-520
Capacity	Center Feeding	60-90	100-130	150-190	225-260
Feeder Opending Size(mm)	Soft Material	≤35	≤40	≤45	≤50
Feeder Opending Size(mm)	Hard Material	≤30	≤35	≤40	≤45
Rotation Speed(r/min)		1700-1890	1520-1690	1360-1510	1180-1310
Power of the Double Motors(kw)		110-150	180-220	264-320	400-440
Overall Dimension(mm)		3700×2150×2100	4140×2280×2425	4560×2447×2778	5000×2700×3300
Power		380V:50Hz
Vibrating Sensor		监测范围：0.1-20mm/s 连续可调Inspection Scope: 0.1-20mm/s, it can be adjusted contimuously
Thin oil lubrication station	Power of Double Oil Pump	2×0.31kw
	Safety	Double oi pumps make sure supply of oil; Stop automatically without oil flow or oil pressure; Water cooled; Heating start the motor in winter
	Overall Dimension(mm)	820×520×1270
	Power of Oil-box Heater Dimension(mm)	2KW
