XL Spiral Sand Washer

XL Spiral Sand Washer: Efficiently cleans sand with a new seal and adjustable overflow weir.
Capacity: 5-260 t/h Feeding : ≤10 mm Power: 5.5-18.5 kw
Material
Suitable for cleaning and grading sand, gravel, and fine/coarse-grained materials, effectively removing soil (dirt) and impurities.
Application
Widely used in highway, hydropower, construction industries for washing, grading, impurity removal, and fine/coarse material separation—especially for building and road construction sand.

Product Features

Single/double spiral options for versatile needs
Novel sealing structure ensures washing-dehydration efficiency
Adjustable overflow weir plate for precise grading
Reliable transmission device for stable operation
Separates dirt/debris from sand effectively
Ideal for building and road construction sand

Specification

ModelXL515XL765XL9202XL920XL1120
2XL1120
Screw Diameter(mm)51576592092011201120
Sink Length(mm)761576207585758597509750
Feeding Size(mm)≤10≤10≤10≤10≤10≤10
Screw Speed(r/min)3826100200175350
Capacity(t/h)
5-1520-6040-11080-22050-130100-260
Power(kw)5.511112×1118.52×18.5
Water Consumption(t/h)6-609-6310-8020-16020-15040-300
Wocatspom can provide customers with technical services on original products and spare parts to ensure worry-free operation.
