Belt Conveyor

Rubber belt conveyors, also known as belt conveyors, operate based on the principle of friction transmission. They are suitable for conveying powdered, granular, and small block materials.

Transportation Speed: 1.3-2.0 (m/s) Throughput: 40-1080 t/h

Get Quotes Whatsapp Engineer

Material

It can process coal, gravel, sand, cement, fertilizer, grain, etc., with the density less than 1.67/t/m*.

Application

The belt conveyor can be used in the range of -20℃to 40℃ambient temperature and the temperature of the aggregates being conveyed is less than 60°C.

Product Features

Operating environment: -20°C to 40°C; material temperature: ≤60°C

Supports customization of fuselage length and assembly form as needed.

Stable operation and high conveying efficiency

Electric roller or drive unit optional

Applicable to materials with a density of <1.67 tons/cubic meter

Mining, building materials, chemicals, grain processing and other fields

Specification

Belt Width	Transport Length(m) / Power(kw)			Transportation Speed(m/s)	Throughput(t/h)
B400	≤12/1.5	12-20/2.2-4	20-25/4-7.5	1.3-1.6	40-80
B500	≤12/3	12-20/4-5.5	20-30/5.5-7.5	1.3-1.6	60-150
B650	≤12/4	12-20/5.5	20-30/7.5-11	1.3-1.6	130-320
B800	≤6/4	6-15/5.5	15-30/7.5-15	1.3-1.6	280-540
B1000	≤10/5.5	10-20/7.5-11	20-40/11-22	1.3-2.0	430-850
B1200	≤10/7.5	10-20/7.5-15	20-40/15-30	1.3-2.0	655-1280
B1400	≤10/11	10-20/11-22	20-40/22-45	1.25-2.0	400-680
B1600	≤10/15	10-20/22-30	20-50/30-75	1.25-2.0	600-1080
